Processional plant KM 200 NEO

The miracle of sound for your procession.

Maximum performance – minimum weight

The KM 200 procession system with innovative engineering guarantees interference-free radio operation, even under extreme conditions (e.g. in the vicinity of LTE transmitting stations).

These mobile sound systems are not mass-produced, but are made specifically for your requirement and needs. Due to the processing of high quality components and the latest lithium battery technology these systems are designed for many years of use.

Every parish has different requirements for a mobile sound system. Accordingly, we also offer different systems and equipment. The table below gives you an overview of the most common radio systems, with different performance. We are happy to assist you in selecting the optimal system and advise you on desired connections and extensions.

Download data sheet

Here you can find the technical data of the KM 200 series clearly arranged in a table:

Model name KM 200 UE KM 200 UD-H KM 200 UD-H/T
Tripod with holder and tripod bag yes yes yes
Carrying strap yes yes yes
Charger yes yes yes
Lithium-ion battery 16.8V /5.8 Ah 16.8V /5.8 Ah 16.8V /5.8 Ah
Operating performance 8 hrs music
10 hrs. language
8 hrs music
10 hrs. language
8 hrs music
10 hrs. language
MP3 player with recording function yes yes yes
Watt 70 70 70
Loudspeaker weatherproof
180°
rotatable
weatherproof
180°
rotatable
weatherproof
180°
rotatable
Radio system German Acoustics SDR 7100 German Acoustics SDR 7100 German Acoustics SDR 7100
Radio frequency 823-832 MHZ (with AA 823 active antennas)
NOW also in Austria
REGISTRATION and free of charge
823-832 MHZ (with AA 823 active antennas)
NOW also in Austria
REGISTRATION and free of charge
823-832 MHZ (with AA 823 active antennas)
NOW also in Austria
REGISTRATION and free of charge
Subject to approval no no no
Channels 100 channels 100 channels 100 channels
LTE blocking filter yes yes yes
Receiver (built-in) 1 2 2
Radio range 80 – 150 m 80 – 150 m 80 – 150 m
Radio handheld microphone 1 2 1
Radio pocket transmitter 1 1 1
Lavalier microphone 1 1 1
Weight 3,9 kg 4,1 kg 4,1 kg

Model name KM 200 VHF-E KM 200 VHF-D/H KM 200 VHF-H/T
Tripod with holder and tripod bag yes yes yes
Carrying strap yes yes yes
Charger yes yes yes
Lithium-ion battery 16.8V /5.8 Ah 16.8V /5.8 Ah 16.8V /5.8 Ah
Operating performance 8 hrs music
10 hrs. language
6,5 h music
8.5 h Language
6,5 h music
8.5 h Language
MP3 player with recording function yes yes yes
Watt 70 45 45
Loudspeaker weatherproof
180°
rotatable
weatherproof
180°
rotatable
weatherproof
180°
rotatable
Radio system German Acoustics VDR 2216 German Acoustics VDR 2216 German Acoustics VDR 2216
Radio frequency VHF 232 and 243 MHz
(Austria 232.825 ~ 249.900 MHZ)
VHF 232 and 243 MHz
(Austria 232.825 ~ 249.900 MHZ)
VHF 232 and 243 MHz
(Austria 232.825 ~ 249.900 MHZ)
Subject to approval no no no
Channels 16 channels 16 channels 16 channels
Interference resistance high high high
LTE blocking filter no no no
Receiver (built-in) 1 2 2
Radio range 70 – 120 m 70 – 120 m 70 – 120 m
Radio handheld microphone 1 2 1
Radio pocket transmitter 1 1 1
Lavalier microphone 1 1 1
Weight 3,9 kg 4,1 kg 4,1 kg

Model name KM 200 2.4-E KM 200 2.4-D/H KM 200 2.4-H/T
Tripod with holder and tripod bag yes yes yes
Carrying strap yes yes yes
Charger yes yes yes
Lithium-ion battery 16.8V /5.8 Ah 16.8V /5.8 Ah 16.8V /5.8 Ah
Operating performance 8 hrs music
10 hrs. language
8 hrs music
10 hrs. language
8 hrs music
10 hrs. language
MP3 player with recording function yes yes yes
Watt 70 70 70
Loudspeaker weatherproof
180°
rotatable
weatherproof
180°
rotatable
weatherproof
180°
rotatable
Radio system Digital Chiayo PWR-2410M Digital Chiayo PWR-2410M Digital Chiayo PWR-2410M
Radio frequency Digital 2.4 GHZ00~2483.5 MHz Digital 2.4 GHZ00~2483.5 MHz Digital 2.4 GHZ00~2483.5 MHz
Subject to approval no no no
Channels 81 channels 81 channels 81 channels
Interference resistance conditional conditional conditional
LTE blocking filter no no no
Receiver (built-in) 1 2 2
Radio range 50 – 70 m 50 – 70 m 50 – 70 m
Radio handheld microphone 1 2 1
Radio pocket transmitter 1 1 1
Lavalier microphone 1 1 1
Weight 3,9 kg 4,1 kg 4,1 kg

Your advantages at a glance:

Warm, natural sound and modern design with rotating mechanism
Both speakers can thus be rotated independently of each other up to 180°, achieving the greatest possible sound efficiency for a wide range of applications. Of course, we also emphasize the unique quality of this model in the combination of warm sound and excellent speech intelligibility.

Can be used indoors and outdoors
The special radiation properties allow the use, both indoors and outdoors (in ANY weather!!). This makes the KM 200 suitable not only for processions, but also for any other event.

NO-interference radio frequency
With our procession system you are safe from unpleasant operational failures due to radio interference. We only use transmitters and receivers that have been approved for these applications by the new EU directives. This allows us to offer the highest level of reliability.

High safety against feedback and whistling
Our special technology saves you from annoying feedback or glaring whistling noises, which are very disturbing especially during liturgical use.

State-of-the-art battery technology
Our powerful special batteries (lithium-ion) know no problems when charging. They are lightweight, durable and maintenance-free. They do not suffer any impairment of performance due to cold or heat. In addition, we supply our batteries with automatic protection against over-discharge and deep discharge. Via the control display on the KM 200, you can see at any time whether your device is ready for the next use.

Wireless microphone system – total freedom of movement
Our wireless microphones, which are delivered according to the current EU guidelines, do not restrict your freedom of movement due to disturbing cabling. Optionally also available as dual radio for a second radio microphone or headset.

Additional input for cable microphone
If two wireless microphones are ever not enough, or if you prefer to use cable microphones, our system also has a connection option via the XLR microphone jack with locking protection and phantom power for condenser microphones.

Connection to stationary church systems
Our KM 200 systems can be equipped with a wide variety of radio systems, depending on requirements. This allows us to offer you maximum compatibility with existing stationary church systems.

Tripod and carrying strap
For stationary operation in the parish hall or at outdoor events, we provide you with a light but very stable tripod made of aircraft aluminum. A comfortable carrying strap for the actual procession is also included as standard.
